Product Overview
Features
- One central pump distributes pre-mixed solution through header system (Pump sold separately)
- Powered by compressed air
- Designed for up-close cleaning
- 25 foot (7.6 meter) coiled discharge tubing
- 65° fan tip for increased coverage
- Ability to add padlock to box
Specifications:
- Power type - Central System
- Chemical pickup type - Supplied with pre-mixed solution from a central system
- Number of products unit can draw from - Supplied with one product
- Discharge line length/diameter - 25 ft. (7.6 m) twin-line tubing, with 1/4 in. (6.35 mm) outside diameter (coiled and bonded)
- Discharge wand/tip type - Polypropylene trigger handle with 65° fan tip
- Output distance - 4-6 ft. (1.2-1.8 m)
- Output volume - 6 gal/min (22.7 l/min)
- Flow rate* - 1 gal/min (3.8 l/min)
- Product height - 16 in. (40.6 cm)
Requirements:
- Compressed air requirements - 40-80 psi (3-5 bar) with 3-6 cfm (85-170 l/min)
- Liquid temperature range - 40-100°F (4.4-37°C)
- Central system requirements - Pre-mixed solution must be supplied by a properly sized header system at 2 gpm and 40-80 psi (3-5 bar)
- Chemical compatibility - Chemical products used with this equipment must be formulated for this type of application and compatible with unit materials and pump seals. For more information on chemical compatibility, consult the manufacturer or SDS for your product or contact our customer service department.
Included:
- control box
- hose and hanger
- wand
- user manual
- pump sold separately
