Product Overview
A
product.
product.- Transfer product at up to 5 gal/min (18.9 l/min)
- Available with Santoprene, Viton, or Kalrez seals
- Operate unit by using manual air button, or timer and solenoid valve
- Includes suction and discharge hoses
| COMPRESSED AIR REQUIREMENTS | Air regulator (R25) factory set at 50 psi (3.4 bar). Operating range is 40 to 80 psi (3 to 5 bar) with 2 CFM (56.6 l/min) |
|---|---|
| LIQUID TEMPERATURE RANGE | 40-100ËšF (4.4-37ËšC) |
| ELECTRICAL REQUIREMENTS | WITH TIMER AND SOLENOID VALVE:120 VAC at 60 Hz, 2 amps (GFCI protected outlet) WITH MANUAL AIR BUTTON: None |
| OPERATING VOLTAGE | WITH TIMER AND SOLENOID VALVE:120 VAC WITH MANUAL AIR BUTTON: None |
| CHEMICAL COMPATIBILITY | Chemical products used with this equipment must be formulated for this type of application and compatible with unit materials and pump seals. For more information on chemical compatibility, consult the manufacturer or MSDS for your product. |
| POWER TYPE | WITH TIMER AND SOLENOID VALVE:Compressed air, electricity WITH MANUAL AIR BUTTON:Compressed air |
|---|---|
| NUMBER OF PRODUCTS UNIT CAN DRAW FROM (AND WHETHER IT DRAWS SIMULTANEOUSLY OR ONE AT A TIME) | One product |
| SUCTION LINE LENGTH/DIAMETER | 8 ft. (2.4 m) hose with 1/2 in. (12.7 mm) inside diameter |
| DISCHARGE HOSE DIAMETER/LENGTH | 8 ft. (2.4 m) hose with 1/2 in. (12.7 mm) inside diameter |
| DISCHARGE WAND/TIP TYPE | None |
| FLOW RATE* | 5 gal/min (18.9 l/min) |
| PUMP SEALS | Santoprene, Viton, or Kalrez |
| TIMER OPERATION TYPE | WITH TIMER AND SOLENOID VALVE:Single shot WITH MANUAL AIR BUTTON: None |
*Dilution rates and flow rates given are based on chemical with viscosity of water and factory air pressure settings.
