Product Description
The Mosmatic DYG Swivel 57.654 is a high-precision, maintenance-free swivel designed for high-pressure, self-rotating cleaning equipment. Built from durable brass with a corrosion-resistant nickel-plated finish, this swivel is ideal for demanding industrial and commercial environments. Featuring a triple bearing system—two radial ball bearings and one thrust ball bearing—it ensures smooth and consistent rotation. The carbide seal system enhances leak protection and extends operational life, while the bulkhead fitting allows for secure, fixed mounting.
Applications
-
Surface cleaners
-
Parts washers
-
Tire and wheel cleaning systems
-
High-pressure rotating equipment
-
Industrial and commercial cleaning applications
Key Features
-
Brass body with corrosion-resistant nickel plating
-
Triple bearing system: 2x radial, 1x thrust ball bearing
-
Carbide seal system for exceptional sealing and wear resistance
-
Maintenance-free design
-
Bulkhead fitting for fixed, secure mounting
-
Thread IN: 3/8” NPTF | Thread OUT: 3/8” NPTF
-
Max Pressure: 4000 PSI
-
Max RPM: 2000
-
Max Temperature: 250°F
-
Overall Diameter: 1.34”
-
Overall Length: 3.42”
-
Nominal Width (NW): 3/8”
-
Wrench Size (SW): 0.87”
Specs
- Pressure: 4000 psi
- Temperature: 250°
- RPM: max 2,000 rpm
- Material Type:
- Inner Part: Stainless steel
- Seal: Carbide
- Throughput/medium: ph 3-12 / filtered 10 microns, compressed air (290 psi)
- Thread In: G1 3/8” NPTF
- Thread Out: G2 3/8” NPTF
- Nominal Width (NW): 3/8”
- Wrench Size 1 (SW1): 0.87"
- Wrench Size 2 (SW2): 0.87"
- Wrench Size 3 (SW3): 1.34"
- Diameter (D) (overall diameter): 1.34"
- Length 1 (L1) (overall length) : 3.42
- Length 2 (L2):
- Weight: 7.4 oz
