Product Overview
A
product.
product.- Draws from concentrated product
- Dilutes at ratios of 14:1 to 320:1
- Powered by compressed air
- Stainless steel ball valve and wand
- Stainless steel fluid fittings
- Quick-change pump
| COMPRESSED AIR REQUIREMENTS | 40-80 psi (3-5 bar) with 5-10 cfm (141-283 l/min) |
|---|---|
| WATER REQUIREMENTS | 10-100 psi (0.69-6.9 bar) Backflow prevention is required – consult local plumbing ordinances for more information. |
| LIQUID TEMPERATURE RANGE | 40-100ËšF (4.4-37ËšC) |
| CHEMICAL COMPATIBILITY | Chemical products used with this equipment must be formulated for this type of application and compatible with unit materials and pump seals. For more information on chemical compatibility, consult the manufacturer or MSDS for your product or contact our customer service department. |
| POWER TYPE | Compressed air |
|---|---|
| CHEMICAL PICKUP TYPE | Draws from concentrated product |
| DILUTION RATIO RANGE (WATER:CHEMICAL)* | 14:1 to 320:1 |
| NUMBER OF PRODUCTS UNIT CAN DRAW FROM (AND WHETHER IT DRAWS SIMULTANEOUSLY OR ONE AT A TIME) | One product |
| SUCTION LINE LENGTH/DIAMETER | 8 ft. (2.4 m) clear hose with 1/4 in. (6.4 mm) inside diameter |
| DISCHARGE HOSE DIAMETER/LENGTH | 75 ft. (15 m) hose, with 3/4 in. (19 mm) inside diameter) |
| DISCHARGE WAND/TIP TYPE | 7 in. (17.8 cm) stainless steel wand with zero tip and ball valve |
| OUTPUT DISTANCE | 25-30 ft. (7-9 m) |
| OUTPUT VOLUME | 20-45 gal/min (75-170 l/min) of foam |
| FLOW RATE* | 2 gal/min (7.6 l/min)) |
| PUMP SEALS | Santoprene, Viton, or Kalrez |
*Dilution rates and flow rates given are based on chemical with viscosity of water and factory air pressure settings.
